射流噴嘴是斜坡、地被植物和灌木灌溉應用的理想解決方案。多股射流為景觀提供低的用水量，最大限度地減少?gòu)搅鳎瑫r(shí)在各種壓力和半徑范圍內提供 2.1 米至 5.3 米的均勻覆蓋。

射程: 2.1 m – 5.3 m

性能

可調角度 25°-360°
多股射流噴灌用水量低，避免徑流
斜坡、地面植被和灌木灌溉應用的理想選擇

Copy Link

S-8A

S-16A

注意

標準性能

注意:

標準性能

注意:

標準性能

注意:

注意

Copy Link

Model S-8A Stream Spray Nozzles Performance Chart

Arc	Pressure		Radius	Flow		Precip mm/hr
	bar	kPa	m	m3/hr	l/min
90°	1.0	100	2.1	0.05	0.9	52	60
	1.5	150	2.2	0.07	1.1	55	64
	2.0	200	2.4	0.08	1.4	57	66
	2.1	210	2.4	0.09	1.4	57	66
	2.5	250	2.6	0.1	1.6	58	67
180°	1.0	100	2.1	0.12	1.9	55	63
	1.5	150	2.2	0.13	2.1	51	58
	2.0	200	2.4	0.14	2.3	47	54
	2.1	210	2.4	0.14	2.3	46	53
	2.5	250	2.6	0.15	2.4	44	50
360°	1.0	100	2.1	0.24	4	56	65
	1.5	150	2.2	0.25	4.2	50	58
	2.0	200	2.4	0.26	4.4	45	52
	2.1	210	2.4	0.26	4.4	44	51
	2.5	250	2.6	0.27	4.6	41	47
Bold = Recommended pressure

Model S-16A Stream Spray Nozzles Performance Chart

Arc	Pressure		Radius	Flow		Precip mm/hr
? Nozzle Blue	bar	kPa	m	m3/hr	l/min
90°	1.0	100	4.3	0.08	1.4	18	21
	1.5	150	4.6	0.1	1.6	18	21
	2.0	200	5	0.11	1.9	18	21
	2.1	210	5	0.11	1.9	18	21
	2.5	250	5.3	0.13	2.1	18	21
180°	1.0	100	4.3	0.14	2.3	14	17
	1.5	150	4.6	0.17	2.8	15	18
	2.0	200	5	0.2	3.3	16	18
	2.1	210	5	0.2	3.4	16	19
	2.5	250	5.3	0.23	3.8	16	19
360°	1.0	100	4.3	0.23	3.9	12	14
	1.5	150	4.6	0.3	5	14	16
	2.0	200	5	0.36	6.1	15	17
	2.1	210	5	0.38	6.3	15	17
	2.5	250	5.3	0.43	7.2	16	18
Bold = Recommended pressure Adjustable: 25° to 360° ? Recommend use of the PRS30 for optimal pressure of 2.1 Bar

Copy Link

應用圖片

工作室

NOZZLE COMPARISON CHART

A Nozzle for Every Occasion
From the water-saving MP Rotator, to standard sprays and side-stripped specialty nozzles, Hunter provides a solution you can trust for years on end.


	MP ROTATOR	MP ROTATOR MP800 SERIES	PRO ADJUSTABLE NOZZLES	PRO-SPRAY FIXED ARC NOZZLES	SIDE STRIP	SHORT RADIUS MICRO SPRAY	STREAM	BUBBLERS
QUICK SPECS
NOZZLE TYPES	HIGH EFFICIENCY ROTATOR NOZZLE	SHORT RADIUS HIGH EFFICIENCY ROTATOR NOZZLE	ADJUSTABLE SPRAY	FIXED SPRAY	FIXED SPRAY	FIXED SPRAY	SPECIALTY NOZZLE	SPECIALTY NOZZLE
RADIUS	2.5–10.7 m	1.8–4.9 m	1.2–5.2 m	1.5–5.2 m	1.5 m x 4.5 m 1.5 m x 9.1 m 2.7 m x 5.5 m	0.6, 1.2, 1.8 m	2.1 m to 5.3 m	0.30–0.46 m
WARRANTY	3 Years	3 Years	2 Years	2 Years	2 Years	2 Years	2 Years	2 Years
FEATURES
ARC	45–360	90–360	0–360	90–360	Rectangle	90 or 180	25-360	90–360
PRECIPITATION SQUARE	Approx. 10 mm/hr	Approx. 20 mm/hr	40–168 mm/hr	41–49 mm/hr	Approx. 85 mm/hr	17-67 mm/hr *without overlap	15-57 mm/hr	N/A
PRECIPITATION TRIANGLE	Approx. 11 mm/hr	Approx. 22 mm/hr	45–193 mm/hr	47–57 mm/hr	Approx. 42.5 mm/hr	17-67 mm/hr *without overlap	17-66 mm/hr	N/A
ADVANCED FEATURES
COLOR CODED
AUTOMATIC MATCHED PRECIPITATION
MAXIMUM WATER EFFICIENCY
PRESSURE COMPENSATING
APPLICATIONS
STRIP PATTERN
STREAM SPRAY
SHORT RADIUS
DEEP WATERING
